The Transceiver Unit consists of four modules. Two modules located in the base part of the unit: a Supply Filter module, an Exciter Control module, and two modules are located in the door part of the unit: a power amplifi er module including fi lter bank and a switched mode power supply. The main wiring is by ribbon cables with Micro Match connectors. RF signals are routed in coaxial cables.
